30 Watt EL34 Stereo Tube Amplifier Done

Leave a Comment / By Mads Barnkob / October 11, 2011

After about 2½ years, the amplifier is now is connected to the destined Isophon BS35 speaker set. My dreams of being able to listen to the real tube sound has been fulfilled.

Read it all here: https://kaizerpowerelectronics.dk/audio/2x30w-el34-tube-amplifier/

EL34 tube amplifier test
