DRSSTC design guide updated with MMC design guide

It only took me a mere 4 years from I first started this article about the MMC until it is now done for public released 🙂 Not that it took me 4 full years to write on it, but it has … Continue reading

Posted in Tesla Coils | Tagged , , , , | Leave a comment

Video gear & workflow: Canon 5D mk3, Rødelink, FPS1000HD and more

A walk-through and demonstration of all my video and audio equipment that I use for youtube videos.

Posted in Technology | Tagged , , , , , | Leave a comment

AC vs DC fuses, high current, explosive destructive testing and theory

Littlefuse 300A 32VDC fuse destructive test Protistor 200A 690VAC fuse (naked) destructive test: Protistor 200A 690VAC fuse (housed) destructive test: High Voltage Fuse Teardown video: https://www.youtube.com/watch?v=XoW5iqfq4tA Semiconductor Fuse Applications Guide: https://ep-us.mersen.com/fileadmin/catalog/Literature/Brochures/BR-Semiconductor-Fuse-Applications-Guide-Brochure.pdf

Posted in High voltage | Tagged , , , , , | Leave a comment

Huawei RRU3928 1800MHz radio base station circuit analysis (part 2 of 2)

The RRU3928 is an outdoor remote radio unit. It processes baseband and RF signal data. With the Software Defined Radio (SDR)technology, the RRU3928 supports the dual-mode operation of any two modes of GSM, UMTS, and LTE through software configuration modification. … Continue reading

Posted in Teardown | Tagged , , , , , , , , , | Leave a comment

Merry Christmas & Happy New Year 2018 (X-ray teardown edition)

Pictures as promised: https://highvoltageforum.net/index.php?topic=523.0 Teaser for the upcoming teardown videos of the Siemens Polyphos 30 x-ray machine, complete with control panel, inverter, collimator, detector/grid plate and x-ray head. Never miss a post, subscribe to email notifications on kaizerpowerelectronics.dk, find it … Continue reading

Posted in News, Teardown | Tagged , , | Leave a comment

Huawei RRU3928 1800MHz radio base station teardown (part 1 of 2)

The RRU3928 is an outdoor remote radio unit. It processes baseband and RF signal data. With the Software Defined Radio (SDR)technology, the RRU3928 supports the dual-mode operation of any two modes of GSM, UMTS, and LTE through software configuration modification. … Continue reading

Posted in Teardown | Tagged , , , , , | 1 Comment

Nokia Siemens Flexi BTS base station teardown: Circuit analysis (part 2 of 2)

Circuit analysis of a Nokia Siemens Networks Flexi BTS base station. This have been in service as a 6 antenna GSM system for mobile telecommunications. GSM/EDGE, WCDMA/HSPA and LTE capable. 2×40 Watt output power. If you missed part 1, see … Continue reading

Posted in Teardown | Tagged , , , , , , , | Leave a comment

Youtube subscription change, please check!

Since youtube changed their notification setup a long while ago, you might be missing out on notifications about my new videos. Be sure to check if you have the “bell” clicked next to the subscription! Thank you 🙂 Check here: https://www.youtube.com/channel/UCSukTlgTEWiL-sl0UeYeJvQ

Posted in News | Tagged | Leave a comment

Moving to a new lab (part 5 and 6) tour and finally its operational

Here you get a short glimpse of the new space for the laboratory and the final setup. This is part 5 and 6 in a series of videos on moving out, moving in and setting up the new lab / … Continue reading

Posted in News | Tagged | Leave a comment

Nokia Siemens Flexi BTS base station teardown: Power amplifier (part 1 of 2)

Teardown of a Nokia Siemens Networks Flexi BTS base station. This have been in service as a 6 antenna GSM system for mobile telecommunications. GSM/EDGE, WCDMA/HSPA and LTE capable. 2×40 Watt output power. also a picture of me pointing at … Continue reading

Posted in Teardown | Tagged , , , , , , , | 3 Comments
